The Surgic Pro surgical micromotor system has evolved into "Surgic Pro2".
There are 3 progress points in operation, safety and wireless connectivity.

3 Progress Points




  • NSK's 'Advanced Handpiece Calibration' (AHC) function corrects the differences in actual handpiece condition using automatic calibration with no load current and load-bearing calibration to achieve accurate torque values for implant surgery.



  • The Osseointegration Monitoring Device, "Osseo 100+" measures the implant stability quotient contactlessly and can be connected using Bluetooth®, permitting ISQ confirmation over a shared interface. You can share and manage the data of those measured ISQ scores at other terminals through Surgic Pro2.

Technology & Function

  • Large Color LCD Touch Panel
    Large Color LCD Touch Panel

    Improved visibility with the large, back-lit, high-contrast LCD panel. The display consists of icons that represent functions and allow for smooth operation. The display can be adjusted to 10 brightness levels. Also, the sensitivity of the touch panel can be adjusted to reliably respond when surgical gloves and surgical barrier sheets are in use.

  • Silent and Smooth Irrigation Pump
    Silent and Smooth Irrigation Pump

    The irrigation pump provides consistent and steady flow operating quietly in the background. Irrigation tube set-up is simple and straight-forward and the pump fits in the design of Surgic Pro2.

  • Linked with a wireless foot control
    Linked with a wireless foot control

    Bluetooth connectivity allows selection of the optimal position without worrying about cable length. The foot controller is 400g lighter than the previous model (hangar included) making it easy to reposition. The "Coolant Solution Flow Volume Button", "Program Button" and "Forward/Reverse Button" may be customized using the 3 installed buttons allowing the operator to choose their preferred mode of operation. The power supply uses 3 AAA batteries, which last about 6 months. A flashing light indicates when the batteries are running low.

  • Linked with iPads
    Linked with iPads

    Installing a dedicated application and connecting an iPad or external devices to the control unit enables real-time display of detailed procedural data, such as the rotation speed and the torque range. Procedural data can also be saved. Data can also be displayed and saved when connecting with Osseo100+. Traceability data management of procedural details allows implant treatment to be tailored to individual patients.

  • The use of high-resolution color LEDs improve the color rendering properties, making it easier to see color contrasts.

Surgic Pro2

Surgic Pro2

COMPLETE SET with X-SG20L

  • Optic
  • Model:Surgic Pro2 OPT
  • Order Code:Y1500763

COMPLETE SET with SG20

  • Non-Optic
  • Model:Surgic Pro2 NON-OPT
  • Order Code:Y1500764

Specifications (Control Unit with AHC)

  • Power Supply
  • AC100-240V 50/60 Hz
  • Max. Pump Output
  • 75 mL/min
  • Programs
  • 8 Programs / Implant Systems
  • Dimensions
  • W 245 × D 235 × H 90 mm
  • LCD Panel
  • 10 brightness levels

Specifications (Micromotor)

  • Torque
  • 5-80 Ncm
  • Motor Speed
  • 200-40,000 min-1
  • Light Power
  • over 32,000 LUX (Optic Micromotor)

Specifications (FOOT CONTROL WIRELESS)

  • Foot Control Functions
  • Coolant Solution Flow Volume Button, PRG(Program) Button, Forward/Reverse Button, Speed Control Pedal

Contents - COMPLETE SET with X-SG20L

  • Control Unit / SGL80M LED Micromotor / X-SG20L Optic Handpiece (20:1 Reduction) / Wireless Foot Control / Irrigation tube (5 pics.) and other accessories

Contents - COMPLETE SET with SG20

  • Control Unit / SG80M Non-Optic Micromotor / SG20 Handpiece (20:1 Reduction) / Wireless Foot Control / Irrigation tube (5 pics.) and other accessories

Compatible Terminals

Supported OSiOS
Compatible modelsiPad (5th generation)
iPad (6th generation)
iPad (7th generation)
iPad (8th generation)
iPad Pro 12.9-inch (3rd generation)
iPad Pro 11-inch
iPad Pro 12.9-inch (4th generation)
iPad Pro 11-inch (2nd generation)
iPad Pro 12.9-inch (5th generation)
iPad Pro 11-inch (3rd generation)

NSK has confirmed that SurgicPro2 App operates properly on the above terminals.
iPad® and iPad Pro® are trademarks of Apple Inc., registered in the U.S. and other countries.
